AES為全球最具研發及生產能力之專業動力電池模組供應商,更是擁有堅強的研發及技術創新能力,可與客戶共同研發設計,依照品牌客戶產品外型設計、電池搭配系統進行動態檢測電池性能的任務,且使其量化。集團也擁有國家級實驗室可自行進行多項信賴度測試、針對各項產品性能、安全性、老化驗證以滿足全球日益嚴苛的法規項目。公司多年來致力於鋰電池模組技術的研發、製造及銷售。目前以銷售輕量型電動載具以及中大型工業儲能系統電池模組為主。其中,輕量型電動載具產品主要應用於室內、戶外移動載具,包含電動自行車、電動摩托車、電動平衡車等。輕量型電動載具的電池模組,中大型工業儲能系統電池模組,近年均呈現快速成長的趨勢。

產品類別 產品描述
兩輪動力載具 電動自行車用鋰電池組、電動摩托車鋰電池組、電動平衡車
中大型工業儲能 儲能系統相關應用、家用儲能、大型儲能站、備援電池系統、工業用電池系統
四輪動力載具




| Slim tube Series


TPS-C01 (360Wh)
Integrated type
360Wh : (21700 Cell) / 36V
Configuration : 10S2P
Dimension (L x W x H) : 420 x 50 x 56.9 mm
Weight (360Wh) : 2.3 kgs
System compability : Shimano Gen2







TPS-C15 (540Wh)
Integrated type
540Wh : (21700 Cell) / 36V
Configuration : 10S3P
Dimension (L x W x H) : 411 x 73.5 x 56.9 mm
Weight (540Wh) : 3.2 kgs
System compability : Shimano Gen2








TPS-C15 (600Wh)
Integrated type
600Wh : (21700 Cell) / 36V
Configuration : 10S3P
Dimension (L x W x H) : 411 x 73.5 x 56.9 mm
Weight (540Wh) : 3.5 kgs
System compability : Shimano Gen2








TPS-C02 (720Wh)
Integrated type
720Wh : (21700 Cell) / 36V
Configuration : 10S4P
Dimension (L x W x H) : 502 x 78 x 60 mm
Weight (720Wh) : 4.1 kgs
System compability : Shimano Gen2







 TPS-C30 (800Wh)
Integrated type
800Wh : (21700 Cell) / 36V
Configuration : 10S4P
Dimension (L x W x H) : 507.5 x 78 x 60.5 mm
Weight (800Wh) : 4.2kgs
System compability : Shimano Gen2











| In-frame tube Series

TPS-C06/TPY-009 (500Wh)
Integrated type / Protable type
500Wh : (18650 Cell) / 36V
Configuration : 10S4P
Dimension (L x W x H) : 385 x 84 x 72 mm
Weight (500Wh) : 3.25kgs
System compability : Shimano Gen2 / Yamaha







 TPS-C07/TPY-003 (630Wh)
Integrated type / Protable type
630Wh : (18650 Cell) / 36V
Configuration : 10S5P
Dimension (L x W x H) : 385 x 84 x 72 mm
Weight (630Wh) : 3.75kgs
System compability : Shimano Gen2 / Yamaha










TPS-C14 / TPY-006 (720Wh)
Integrated type / Protable type
720Wh : (21700 Cell) / 36V
Configuration : 10S4P
Dimension (L x W x H) : 408 x 83 x 72 mm
Weight (720Wh) : 4 kgs
System compability : Shimano Gen2 / Yamaha








TPS-C31 / TPY-015 (800Wh)
Integrated type / Protable type
800Wh : (21700 Cell) / 36V
Configuration : 10S4P
Dimension(L x W x H):408.85 x 83.2 x 72.12 mm
Weight (800Wh) : 3.8 kgs
System compability : Shimano Gen2 / Yamaha












Range extender Series



TPS-C25 (250Wh)
Range extender type
250Wh : (18650 Cell) / 36V
Configuration : 10S2P
Dimension (L x W x H) : 205 x 98 x 77.7 mm
Weight (250Wh) : 1.5 kgs
System compability : Shimano Gen2 / Yamaha











TPS-C13 (360Wh)
Range extender type
360Wh : (21700 Cell) / 36V
Configuration : 10S2P
Dimension (L x W x H) : 319 x 79 x 94 mm
Weight (250Wh) : 2.3 kgs
System compability : Shimano Gen2 / Yamaha















Rear rack Series

VT-01 / TPY-016 (630Wh)
Rear rack type
630Wh : (18650 Cell) / 36V
Configuration : 10S5P
Dimension (L x W x H) : 387.6 x 132.1 x 74.2 mm
Weight (250Wh) : 4.56 kgs
System compability : Shimano Gen1 / Yamaha
