AES-KY is a professional power battery module supplier with the best R&D and production capacity in the world. It also has strong R&D and technological innovation capabilities to jointly develop and design with customers. AES is able to conduct dynamic testing of the performance of batteries based on the product appearance design and battery matching system of brand customers and quantify the results. The Group also owns a national-level laboratory and is able to conduct many credibility tests for verifying the performance, safety, and aging of each product, to meet the increasingly rigorous regulations.For many years, AES-KY has been committed to the R&D, manufacture and sale of lithium battery module technologies. Currently, it mainly sells the battery modules for lightweight electric vehicles and mid- and large-sized industrial energy storage systems. Of these, lightweight electric vehicle products are mainly used in indoor and outdoor mobile vehicles, including electric bicycles, electric scooters, and electric self-balancing personal transporters. Battery modules for light electric vehicles and battery modules for mid- and large-sized industrial energy storage systems have shown a rapid growth trend in recent years.
Product category | Product description |
Light Electric Vehicle | Li-ion Battery Pack for E-bike, E-Scooter |
Industrial Energy Solution | Energy Storage Solution, Battery Backup Solution, Industrial related Battery Application |
Automotive | Li-ion Battery Pack for EV, Li-ion Start Battery, Battery Module of E-bus and EV, BMS (Battery Management System) |
| Slim tube Series
TPS-C01 (360Wh) .Integrated type .360Wh : (21700 Cell) / 36V .Configuration : 10S2P .Dimension (L x W x H) : 420 x 50 x 56.9 mm .Weight (360Wh) : 2.3 kgs .System compability : Shimano Gen2 |
TPS-C15 (540Wh) .Integrated type .540Wh : (21700 Cell) / 36V .Configuration : 10S3P .Dimension (L x W x H) : 411 x 73.5 x 56.9 mm .Weight (540Wh) : 3.2 kgs .System compability : Shimano Gen2 |
TPS-C15 (600Wh) .Integrated type .600Wh : (21700 Cell) / 36V .Configuration : 10S3P .Dimension (L x W x H) : 411 x 73.5 x 56.9 mm .Weight (540Wh) : 3.5 kgs .System compability : Shimano Gen2 |
TPS-C02 (720Wh) .Integrated type .720Wh : (21700 Cell) / 36V .Configuration : 10S4P .Dimension (L x W x H) : 502 x 78 x 60 mm .Weight (720Wh) : 4.1 kgs .System compability : Shimano Gen2 |
|
TPS-C30 (800Wh) .Integrated type .800Wh : (21700 Cell) / 36V .Configuration : 10S4P .Dimension (L x W x H) : 507.5 x 78 x 60.5 mm .Weight (800Wh) : 4.2kgs .System compability : Shimano Gen2 |
| In-frame tube Series
TPS-C06/TPY-009 (500Wh) .Integrated type / Protable type .500Wh : (18650 Cell) / 36V .Configuration : 10S4P .Dimension (L x W x H) : 385 x 84 x 72 mm .Weight (500Wh) : 3.25kgs .System compability : Shimano Gen2 / Yamaha |
TPS-C07/TPY-003 (630Wh) .Integrated type / Protable type .630Wh : (18650 Cell) / 36V .Configuration : 10S5P .Dimension (L x W x H) : 385 x 84 x 72 mm .Weight (630Wh) : 3.75kgs .System compability : Shimano Gen2 / Yamaha |
TPS-C14 / TPY-006 (720Wh) .Integrated type / Protable type .720Wh : (21700 Cell) / 36V .Configuration : 10S4P .Dimension (L x W x H) : 408 x 83 x 72 mm .Weight (720Wh) : 4 kgs .System compability : Shimano Gen2 / Yamaha |
TPS-C31 / TPY-015 (800Wh) .Integrated type / Protable type .800Wh : (21700 Cell) / 36V .Configuration : 10S4P .Dimension(L x W x H):408.85 x 83.2 x 72.12 mm .Weight (800Wh) : 3.8 kgs .System compability : Shimano Gen2 / Yamaha |
| Range extender Series
TPS-C25 (250Wh) .Range extender type .250Wh : (18650 Cell) / 36V .Configuration : 10S2P .Dimension (L x W x H) : 205 x 98 x 77.7 mm .Weight (250Wh) : 1.5 kgs .System compability : Shimano Gen2 / Yamaha |
TPS-C13 (360Wh) .Range extender type .360Wh : (21700 Cell) / 36V .Configuration : 10S2P .Dimension (L x W x H) : 319 x 79 x 94 mm .Weight (250Wh) : 2.3 kgs .System compability : Shimano Gen2 / Yamaha |
| Rear rack Series
VT-01 / TPY-016 (630Wh) .Rear rack type .630Wh : (18650 Cell) / 36V .Configuration : 10S5P .Dimension (L x W x H) : 387.6 x 132.1 x 74.2 mm .Weight (250Wh) : 4.56 kgs .System compability : Shimano Gen1 / Yamaha |
