AES-KY is a professional power battery module supplier with the best R&D and production capacity in the world. It also has strong R&D and technological innovation capabilities to jointly develop and design with customers. AES is able to conduct dynamic testing of the performance of batteries based on the product appearance design and battery matching system of brand customers and quantify the results. The Group also owns a national-level laboratory and is able to conduct many credibility tests for verifying the performance, safety, and aging of each product, to meet the increasingly rigorous regulations.For many years, AES-KY has been committed to the R&D, manufacture and sale of lithium battery module technologies. Currently, it mainly sells the battery modules for lightweight electric vehicles and mid- and large-sized industrial energy storage systems. Of these, lightweight electric vehicle products are mainly used in indoor and outdoor mobile vehicles, including electric bicycles, electric scooters, and electric self-balancing personal transporters. Battery modules for light electric vehicles and battery modules for mid- and large-sized industrial energy storage systems have shown a rapid growth trend in recent years.

Product category Product description
Light Electric Vehicle Li-ion Battery Pack for E-bike, E-Scooter
Industrial Energy Solution Energy Storage Solution, Battery Backup Solution, Industrial related Battery Application
Automotive Li-ion Battery Pack for EV, Li-ion Start Battery, Battery Module of E-bus and EV, BMS (Battery Management System)



| Slim tube Series


TPS-C01 (360Wh)
Integrated type
360Wh : (21700 Cell) / 36V
Configuration : 10S2P
Dimension (L x W x H) : 420 x 50 x 56.9 mm
Weight (360Wh) : 2.3 kgs
System compability : Shimano Gen2







TPS-C15 (540Wh)
Integrated type
540Wh : (21700 Cell) / 36V
Configuration : 10S3P
Dimension (L x W x H) : 411 x 73.5 x 56.9 mm
Weight (540Wh) : 3.2 kgs
System compability : Shimano Gen2








TPS-C15 (600Wh)
Integrated type
600Wh : (21700 Cell) / 36V
Configuration : 10S3P
Dimension (L x W x H) : 411 x 73.5 x 56.9 mm
Weight (540Wh) : 3.5 kgs
System compability : Shimano Gen2








TPS-C02 (720Wh)
Integrated type
720Wh : (21700 Cell) / 36V
Configuration : 10S4P
Dimension (L x W x H) : 502 x 78 x 60 mm
Weight (720Wh) : 4.1 kgs
System compability : Shimano Gen2







 TPS-C30 (800Wh)
Integrated type
800Wh : (21700 Cell) / 36V
Configuration : 10S4P
Dimension (L x W x H) : 507.5 x 78 x 60.5 mm
Weight (800Wh) : 4.2kgs
System compability : Shimano Gen2










| In-frame tube Series

TPS-C06/TPY-009 (500Wh)
Integrated type / Protable type
500Wh : (18650 Cell) / 36V
Configuration : 10S4P
Dimension (L x W x H) : 385 x 84 x 72 mm
Weight (500Wh) : 3.25kgs
System compability : Shimano Gen2 / Yamaha







 TPS-C07/TPY-003 (630Wh)
Integrated type / Protable type
630Wh : (18650 Cell) / 36V
Configuration : 10S5P
Dimension (L x W x H) : 385 x 84 x 72 mm
Weight (630Wh) : 3.75kgs
System compability : Shimano Gen2 / Yamaha










TPS-C14 / TPY-006 (720Wh)
Integrated type / Protable type
720Wh : (21700 Cell) / 36V
Configuration : 10S4P
Dimension (L x W x H) : 408 x 83 x 72 mm
Weight (720Wh) : 4 kgs
System compability : Shimano Gen2 / Yamaha








TPS-C31 / TPY-015 (800Wh)
Integrated type / Protable type
800Wh : (21700 Cell) / 36V
Configuration : 10S4P
Dimension(L x W x H):408.85 x 83.2 x 72.12 mm
Weight (800Wh) : 3.8 kgs
System compability : Shimano Gen2 / Yamaha










Range extender Series


TPS-C25 (250Wh)
Range extender type
250Wh : (18650 Cell) / 36V
Configuration : 10S2P
Dimension (L x W x H) : 205 x 98 x 77.7 mm
Weight (250Wh) : 1.5 kgs
System compability : Shimano Gen2 / Yamaha











TPS-C13 (360Wh)
Range extender type
360Wh : (21700 Cell) / 36V
Configuration : 10S2P
Dimension (L x W x H) : 319 x 79 x 94 mm
Weight (250Wh) : 2.3 kgs
System compability : Shimano Gen2 / Yamaha













Rear rack Series

VT-01 / TPY-016 (630Wh)
Rear rack type
630Wh : (18650 Cell) / 36V
Configuration : 10S5P
Dimension (L x W x H) : 387.6 x 132.1 x 74.2 mm
Weight (250Wh) : 4.56 kgs
System compability : Shimano Gen1 / Yamaha
