AES为全球最具研发及生产能力之专业动力电池模块供货商,更是拥有坚强的研发及技术创新能力,可与客户共同研发设计,依照品牌客户产品外型设计、电池搭配系统进行动态检测电池性能的任务,且使其量化。集团也拥有国家级实验室可自行进行多项信赖度测试、针对各项产品性能、安全性、老化验证以满足全球日益严苛的法规项目。公司多年来致力于锂电池模块技术的研发、制造及销售。目前以销售轻量型电动载具以及中大型工业储能系统电池模块为主。其中,轻量型电动载具产品主要应用于室内、户外移动载具,包含电动自行车、电动摩托车、电动平衡车等。轻量型电动载具的电池模块,中大型工业储能系统电池模块,近年均呈现快速成长的趋势。

产品类别 产品描述
两轮动力载具 电动自行车用锂电池组、电动摩托车锂电池组、电动平衡车
中大型工业储能 储能系统相关应用、家用储能、大型储能站、备援电池系统、工业用电池系统
四轮动力载具 混合动力汽车及电动车电池组、汽车用启动锂电池组、电动汽车/巴士电池模块、车用电池管理系统




| Slim tube Series


TPS-C01 (360Wh)
Integrated type
360Wh : (21700 Cell) / 36V
Configuration : 10S2P
Dimension (L x W x H) : 420 x 50 x 56.9 mm
Weight (360Wh) : 2.3 kgs
System compability : Shimano Gen2







TPS-C15 (540Wh)
Integrated type
540Wh : (21700 Cell) / 36V
Configuration : 10S3P
Dimension (L x W x H) : 411 x 73.5 x 56.9 mm
Weight (540Wh) : 3.2 kgs
System compability : Shimano Gen2








TPS-C15 (600Wh)
Integrated type
600Wh : (21700 Cell) / 36V
Configuration : 10S3P
Dimension (L x W x H) : 411 x 73.5 x 56.9 mm
Weight (540Wh) : 3.5 kgs
System compability : Shimano Gen2








TPS-C02 (720Wh)
Integrated type
720Wh : (21700 Cell) / 36V
Configuration : 10S4P
Dimension (L x W x H) : 502 x 78 x 60 mm
Weight (720Wh) : 4.1 kgs
System compability : Shimano Gen2







 TPS-C30 (800Wh)
Integrated type
800Wh : (21700 Cell) / 36V
Configuration : 10S4P
Dimension (L x W x H) : 507.5 x 78 x 60.5 mm
Weight (800Wh) : 4.2kgs
System compability : Shimano Gen2










| In-frame tube Series

TPS-C06/TPY-009 (500Wh)
Integrated type / Protable type
500Wh : (18650 Cell) / 36V
Configuration : 10S4P
Dimension (L x W x H) : 385 x 84 x 72 mm
Weight (500Wh) : 3.25kgs
System compability : Shimano Gen2 / Yamaha







 TPS-C07/TPY-003 (630Wh)
Integrated type / Protable type
630Wh : (18650 Cell) / 36V
Configuration : 10S5P
Dimension (L x W x H) : 385 x 84 x 72 mm
Weight (630Wh) : 3.75kgs
System compability : Shimano Gen2 / Yamaha










TPS-C14 / TPY-006 (720Wh)
Integrated type / Protable type
720Wh : (21700 Cell) / 36V
Configuration : 10S4P
Dimension (L x W x H) : 408 x 83 x 72 mm
Weight (720Wh) : 4 kgs
System compability : Shimano Gen2 / Yamaha








TPS-C31 / TPY-015 (800Wh)
Integrated type / Protable type
800Wh : (21700 Cell) / 36V
Configuration : 10S4P
Dimension(L x W x H):408.85 x 83.2 x 72.12 mm
Weight (800Wh) : 3.8 kgs
System compability : Shimano Gen2 / Yamaha










Range extender Series


TPS-C25 (250Wh)
Range extender type
250Wh : (18650 Cell) / 36V
Configuration : 10S2P
Dimension (L x W x H) : 205 x 98 x 77.7 mm
Weight (250Wh) : 1.5 kgs
System compability : Shimano Gen2 / Yamaha











TPS-C13 (360Wh)
Range extender type
360Wh : (21700 Cell) / 36V
Configuration : 10S2P
Dimension (L x W x H) : 319 x 79 x 94 mm
Weight (250Wh) : 2.3 kgs
System compability : Shimano Gen2 / Yamaha













Rear rack Series

VT-01 / TPY-016 (630Wh)
Rear rack type
630Wh : (18650 Cell) / 36V
Configuration : 10S5P
Dimension (L x W x H) : 387.6 x 132.1 x 74.2 mm
Weight (250Wh) : 4.56 kgs
System compability : Shimano Gen1 / Yamaha
